TMR 3-1211HI
Manufacturer:
TRACO Power
Mfr.Part #:
TMR 3-1211HI
Datasheet:
Description:
DC to DC Converters 21.80mmL×9.20mmW×11.10mmH Through Hole Nominal Input Voltage:12 V Min Input Voltage:9 V Max Input Voltage:18 V 81 %
| Parameter | Value |
|---|---|
| Length | 21.8 mm |
| Width | 9.2 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 7 |
| Height | 11.1 mm |
| Packaging | Tube |
| Depth | 9.2 mm |
| RoHS | Compliant |
| Weight | 4.8 g |
| Min Input Voltage | 9 V |
| Output Current | 600 mA |
| Output Voltage | 5 V |
| Max Input Voltage | 18 V |
| Number of Outputs | 1 |
| Isolation Voltage | 3 kV |
| Output Power | 3 W |
| Efficiency | 81 % |
| Nominal Input Voltage | 12 V |
| Isolation | Isolated |
| Output Current-Channel 1 | 600 mA |
| Output Voltage-Channel 1 | 5 V |
Stock: 4
Distributors
pcbx
pcbxUnit Price$15.21347
Ext.Price$15.21347
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $15.21347 | $15.21347 |
| 10 | $14.11233 | $141.12330 |
| 25 | $13.84689 | $346.17225 |
| 50 | $13.58654 | $679.32700 |
| 100 | $13.36768 | $1336.76800 |
| 300 | $12.88004 | $3864.01200 |
| 500 | $12.41016 | $6205.08000 |
